Inductoplast
Features:
-
High temperature resistant
-
Highly electrically insulating at elevated temperatures
-
Doesn’t absorb moisture after complete cure.
-
Neutral in nature against acidic/alkaline atmosphere
-
Anti-‐oxidant and anti-‐corrosive
-
Highly thermal conducting and bonding increases with rise in temperature
-
Prevents sparking and doesn’t carbonize
-
High dielectric strength and thermal shock resistance
-
Longer service life and prevents power loss
-
Maintains leakage current at minimum through-‐out coil’s service life
-
Prevents sparking and doesn’t carbonize
Industry Applications:
| Density | 1.45 – 1..5 Kg/Liter @ 250 C |
|---|---|
| Colour | Brown |
| Solid Contents | 58% + 2% |
| Service temperature | 3000C + 10% |
| Electrical properties | Fully cured 1mm thick coating at 1400C for 8-‐9 hours: |
| Di-electric strength | 2000C: 60 KV |
| 24 hours water immersion | 300C: 60 KV |
| Thermal Conductivity | ~ 25-‐26 W/mK |
| Adhesion to metal | Excellent after curing |
| 24 hours acid vapors | 1000C: >60 KV |
